E510



E510 High performance, OEMs Sensorless Vector Drive


A compact, robust, and versatile AC Drive with standard modbus communication. Advanced sensorless vector control function offers the most economical motor drive solution for industrial applications and OEM's. Two enclosure types are available: IP20 & IP66.

Key Features

  • 230V single phase
  • 200V and 400V three pahses
  • 0.37 – 18.5kW
  • Advanced sensorless vector control
  • IP20 and IP66
  • Temperature controlled fan cooling
  • Integrated EMC filter C2 (C1 option)
  • EMC filter earth link disconnector
  • 32 bit CPU
  • ModBus / RS485 integrated, Profibus, DeviceNet, CANopen and Ethernet(TCP/IP) options
  • Multi pre-set speeds with individual Acc/ Dec times
  • PLC functions (By ladder program)
  • Integrated Dynamic Braking module
  • PC programming software
  • Remote keypad / copy unit option
  • 650Hz output frequency (1000Hz option)
