JSMA



JSMA - High Quality and Performance Servo Motor

The great diversity from small inertia to high power ensures a wide range of applications starting with high dynamic pick and place applications up to the use in machine tools. High protection degree (max. IP67) permits the use in nearly all environmental conditions (400V 400W~15kW Available end of 2014).



Key Features

  • Rated power output:50W-15kW
  • Frame size: 42/60/76/80/86/130/180/220mm
  • Encoder resolution: 2500ppr/8192ppr/17-bit (Incremental) 15-bit(Absolute)
  • Rated speed ranges: 1000/1500/2000/3000 rpm
  • Excellent performance, smooth operation, high quality and stability
  • A full range of performance with outstanding high torque output
  • Low noise, low vibration, elegant appearance and easy installation
  • Enclosure: IP67
